Video Capture USB™ Hub

The Video Capture USB™ Hub is a dual-purpose device that combines an HDMI™ capture card with a USB-C® hub. With the 1080p video capture and 4K USB-C® display, as well as Power Delivery 3.0, you can stream in UHD without interruptions while charging your connected device. It also includes two SuperSpeed USB™ 5Gbps ports for further peripheral connectivity. The compact and lightweight design makes this video capture hub perfect for mobile streaming. When not used for streaming, it acts as a standard USB-C® hub, allowing you to add two additional USB™ peripherals and a 4K HDMI™ display. It also supports upstream charging to keep your laptop powered while in use.

System Requirements:

For UVC Capture - Recommended software: OBS™ / CameraFi™ Live

• Available USB-C® port that supports USB™ Power Delivery 2.0 or 3.0
• Windows® 10 / 11
• macOS® X 10.10 or later with UVC support
• Chrome OS™ with UVC support
• Android™ 7 and higher

For USB-C® Hub

• Available USB-C® port that supports DisplayPort™ alt mode and USB™ Power Delivery 2.0 (USB™ 3.2 is recommended). Please refer to the manufacturer of your hardware for more information on your device.
• DisplayPort™ v1.2 required on graphics card or video source to support 4K @ 30 Hz resolution

For USB-C® Game Consoles

• When using your game console, we recommend using a charger higher than 30W PD USB-C® to charge your console.

Special Notes:

• The JVA01 can connect to a USB-C® port that does not support Power Delivery, but it will not pass power through the connected device.
• The HDMI™ Input port is for capture only. Additional displays will not output from this port. An external display can be connected through the HDMI™ Output port instead.
• For UVC capture, the 3.5 mm audio jack only works if the host connected to the monitor has built-in speakers.
